Product Summary

The M-190 is an Enphase Energy Microinverter System. It improves energy harvest, increases reliability, and dramatically simplifies design, installation and management of solar power systems. The M-190 includes the microinverter, the Envoy Communications Gateway, and the web-based Enlighten monitoring and analysis website.

Parametrics

M-190 absolute maximum ratings: (1)aximum output power: 190W; (2)Nominal output current: 920mA; (3)Nominal voltage/range: 208V/183V-229V; (4)Extended voltage/range: 208V/179V-232V; (5)Nominal frequency/range: 60.0/59.3-60.5; (6)Extended frequency/range: 60.0/59.2-60.6; (7)Power factor: >0.95; (8)Maximum units per branch: 21.

Features

M-190 features: (1)Integrated monitoring and powerline communications; (2)15 year warranty; (3)14AWG integrated cable for 15A branch circuit; (4)NEMA 6 enclosure rating; (5)CSA listed per UL 1741/IEE1547.

Diagrams

M-190 dimensions
