Product Summary
The 113A2 Power Module provides highly reliable power for digital and telecommunications applications. Each nonisolated switching regulator operates from a 5 Vdc input. The 113A2 provides –5V, –12V, –15V, and –130V outputs.
Parametrics
Absolute maximum ratings: (1)Input Voltage: 7 Vdc max; (2)Operating Ambient Temperature*: 0 to 70 ℃; (3)Storage Temperature: -40 to 125 ℃.
Features
Features: (1)High reliability; (2)Low profile; (3)Small size: 24.4 mm x 17.8 mm x 11.2 mm (0.96 in. x 0.70 in. x 0.44 in.); (4)Printed-circuit board mountable; (5)No minimum load; (6)UL* 1950 Recognized; (7)Operating ambient temperature range: 0 ℃ to 70 ℃.
Diagrams
 |
