Product Summary
The MSM9006-02G3-BK is an LCD driver for a 1/3 duty dynamic display. It can directly drive an LCD with a maximum of 123 segments. Its package is QFP.
Parametrics
Absolute maximum ratings: (1)Supply Voltage, VDD: –0.3 to +6.5 V when Ta=25℃; (2)Input Voltage, VI: –0.3 to VDD+0.3 V when Ta=25℃; (3)Storage Temperature, TSTG : –55 to +150 ℃.
Features
Features: (1)41 segment outputs (when LED and output port are not used); (2)One LED can be driven directly; (3)Up to five output ports are available; (4)The interface with the CPU is a serial interface using LOAD, DATA I/O, and CLOCK; (5)Built-in RC oscillation circuit for LCD alternating current drive; (6)Built-in voltage dividing resistor for bias voltage generation.
